Name |
: |
Rubber Bulbs/ Injection sites for
infusion and transfusion sets. |
|
Application |
: |
Rubber Bulb is a component of
infusion sets, through which medicine can be injected into
the cannula. |
|
|
|
|
|
 |
| Product Code |
: |
JLB1 / JIB1 |
| Outer Diameter |
: |
12.00mm |
| Stem Diameter |
: |
6.00mm |
| Inner Diameter |
: |
3.10mm |
| Length |
: |
47.00mm |
| Material |
: |
Natural Rubber (JLB1) / Polyisoprene
(Latex Free) (JIB1) |
|
|
|
|
|
 |
| Product Code |
: |
JLB2 / JIB2 |
| Outer Diameter |
: |
9.00mm |
| Stem Diameter |
: |
5.90mm /
6.10mm |
| Inner Diameter |
: |
2.6mm |
| Length |
: |
44.00mm |
| Material |
: |
Natural
Rubber (JLB2) / Polyisoprene (Latex Free) (JIB2) |
|
|
|
|
|
 |
| Product Code |
: |
JLB4A /
JIB4A |
| Outer Diameter |
: |
9.20mm |
| Stem Diameter |
: |
5.40mm / 6.50mm |
| Inner Diameter |
: |
2.60mm |
| Length |
: |
41.00mm |
| Material |
: |
Natural
Rubber (JLB4A) / Polyisoprene (Latex Free) (JIB4A) |
|
|
|
|
|
 |
| Product Code |
: |
JLB5A /
JIB5A |
| Outer Diameter |
: |
9.00mm |
| Stem Diameter |
: |
6.00mm |
| Inner Diameter |
: |
2.70mm |
| Length |
: |
44.00mm |
| Material |
: |
Natural
Rubber (JLB5A) / Polyisoprene (Latex Free) (JIB5A) |
|
|
Name |
: |
Rubber Discs
for Volumetric Sets. |
|
Application |
: |
Rubber Discs
used in Volumetric sets act as float Indicators and
automatically shut off the fluid line when the chamber
becomes empty to prevent any air entrapment in the fluid
line or any air entry into the patients Venous system. |
|
|
 |
| Product Code |
: |
JLF2 / JIF2 |
| Outer Diameter |
: |
31.00mm |
| Thickness |
: |
3.00mm |
|
Film Thickness |
: |
0.60mm |
| Material |
: |
Natural
Rubber (JLF2) / Polyisoprene (Latex Free) (JIF2) |
|
|
|
|
|
 |
| Product Code |
: |
JLF3/JIF3/JSF3 |
| Outer Diameter |
: |
22.50mm |
| Thickness |
: |
0.90mm |
| Film
Thickness |
: |
0.50mm |
| Material |
: |
Natural
Rubber (JLF3) / Polyisoprene (Latex Free)(JIF3)
/ Silicon
(JSF3) |
|
|
Name |
: |
Rubber Caps
& Plugs for Y- Connections |
|
Application |
: |
Used in
Y-Connections, provide injection part for extra medication
to be administered through infusion/transfusion sets. |
|
|
 |
| Product Code |
: |
JLYA/ JIYA |
| Outer Diameter |
: |
7.60mm |
| Thickness |
: |
3.30mm |
| Material |
: |
Natural
Rubber (JLYA) / Polyisoprene (Latex Free) (JIYA) |
|
|
|
|
|
 |
| Product Code |
: |
JLYS / JIYS |
| Outer Diameter |
: |
7.20mm |
| Inner Diameter
|
: |
4.90mm |
| Thickness |
: |
10.00mm |
| Material |
: |
Natural
Rubber (JLYS) / Polyisoprene (Latex Free) (JIYS) |
|
|
Name |
: |
Pharmaceutical Rubber Closures |
|
Application |
: |
Used for air
tight sealing of vials / bottles for I.V.Solutions. |
|
Sizes |
: |
13mm, 13mm (Lyophilisation
Type), 20mm (Regular & Non-Pop), 32mm. |
|
|
 |
| Product Code |
: |
20JB2 /
20JBB4 |
| Total Height |
: |
8.40mm |
| Flap
Diameter |
: |
19.00mm |
| Flap
Thickness |
: |
3.40mm |
|
Plug Diameter
|
: |
13.15mm |
| Material |
: |
Butyl
(20JB2) /
Bromobutyl(20JBB4) |
|
|
|
|
|
 |
| Product Code |
: |
20JB3 / 20JBB5 (Non-Pop Design) |
| Total Height |
: |
8.60mm |
| Flap
Diameter |
: |
19.10mm |
| Flap
Thickness |
: |
3.20mm |
|
Groove Diameter |
: |
13.00mm |
| Plug
Diameter |
: |
13.60mm |
| Material |
: |
Butyl (20JB3) /
Bromobutyl
(20JBB5) |
|
|
|
|
|
 |
| Product Code |
: |
6JKB1 / 6JKBB1 |
| Total Height |
: |
13.00mm |
| Flap
Diameter |
: |
31.00mm |
| Flap
Thickness |
: |
4.30mm |
| Plug
Diameter |
: |
21.40mm |
| Material |
: |
Butyl
(6JKB1) /
Bromobutyl(6JKBB1) |
|
|
|
|
|
 |
| Product Code |
: |
13JB2 / 13JBB2 |
| Total Height |
: |
7.00mm |
| Flap
Diameter |
: |
12.50mm |
| Flap
Thickness |
: |
2.20mm |
| Plug
Diameter |
: |
7.50mm |
| Material |
: |
Butyl
(13JB2) /
Bromobutyl(13JBB2) |
|
|
|
|
|
 |
| Product Code |
: |
13JBL2 / 13JBBL2 (Lyophilisation Type) |
| Total Height |
: |
11.00mm |
| Flap
Diameter |
: |
12.50mm |
| Flap
Thickness |
: |
2.00mm |
| Plug
Diameter |
: |
7.50mm |
| Material |
: |
Butyl (13JBL2)
/
Bromobutyl (13JBBL2) |
|
|
Name |
: |
Rubber Plugs
for Vaccutainers and Rubber Sleeves/Covers for blood
Collection needle. |
|
Application |
: |
Rubber
Plug prevents leakage of vaccum from the Vaccutainers.
Rubber Sleeve is used on blood collection needle to stop
blood flow after use and prevent contamination. |
|
|
 |
| Sizes |
: |
As per
customer requirement |
| Material |
: |
Rubber Plug:
Butyl / Bromobutyl
Rubber Sleeve: Natural Rubber / Synthetic Rubber |
|
|
Name |
: |
Rubber Gaskets for Disposable Syringes |
|
Application |
: |
Used in
disposable Syringe for sealing between plunger and barrel. |
|
 |
| Sizes |
: |
2, 3, 5, 10, 20, 50ml in various designs /as per customer
requirement |
| Material |
: |
Natural Rubber, Butyl / Bromobutyl Rubber |
|
|
Name |
: |
Automobile & Industrial Rubber Products |
|
Application |
: |
O-Rings,
Bellows, Seals, Gaskets, Dampers, Blocks, Rubber to Metal
Bonded Components and Fuel Tubes. |
|
|
 |
| Sizes |
: |
As per customer requirement |
| Material |
: |
Natural
Rubber / SBR / Polybutadiene / EPDM / Nitrile / HNBR/
Neoprene / PVC/NBR / Viton / Silicon / Butyl / Bromobutyl |
|
The above products can also be customized as per
specific requirements. New products can be developed at very short lead times.
|
